The ECO UNIC URW-295-3 , powered by a 3.1kw AC motor and 48v DC rechargeable battery is a versatile spider crane with Zero emissions whilst it retains all the benefits of the standard 295 model, but sees the addition of variable, adjustable outriggers, enabling this mini crane to operate around fixed obstacles on site to suit the unique lifting requirements of each project.
The addition of variable outriggers means this mini crane can operate in spaces where other mini cranes cannot. The adjustable outriggers reduce the working footprint of this already compact mini machine, making it ideal for working in extremely tight and small spaces. Further enhancements include slew limitation, variable slew limitation, height limitation and variable height limitation as standard.
With a width of just 690mm, the URW-295 Eco can access through small spaces yet comes with a heavy lifting capacity of 2.9 tonnes. The 8.65m boom provides a maximum lifting height of 8.8m, whilst an optional fly jib gives a further 1500mm reach which can then increase to 10.47 with a fixed hook where required.
| Capacity | 2.9t x 1.4m |
| Max working height | Approx:8m (9.8m with manual fly jib, 10.47m with fixed hook) |
| Max working radius | 8.41m |
| Boom length | 53 – 8.65m |
| Weight | 2350kg (2415kg with fly jib) |
| Power source | 48v DC rechargeable battery (charger 200/240v single phase 15A) & (charger 110v single phase 32A) |
